KIP 9900 - Manual (Page 39)

Chapter 2 Basic Operations 2-17
2. 4. 1 Multi-feeding of cut sheet media
Multiple cut sheet feeding (50 sheets max) is available when the size is narrower than A2 (594mm)
or 24”. The followings are the sizes that can be fed by multi-feeding. (Orientation must be
landscape)
Metric : 297mm x 210mm (A4)
Inch : 11” x 8.5” 18” x 12”
420mm x 297mm (A3) 12” x 9” 22” x 17”
594mm x 420mm (A2) 17” x 11” 24” x 18”
1. Select the bypass feeding mode on the outer device.
2. Slide the Cut Sheet Guides and place at the
requested size guides.
3. Arrange the edges of media, put the media on the Bypass Feeder, and move them forward
until the leading edges contact the feeding roller.
NOTE
Landscape feeding only is available.
NOTE
(1) Do not attempt to make multi-feeding with other sizes of media as it will result in mis-feed
or duplicate feeding. The internal mechanism of KIP 9900 may damage in the worst case.
(2) Do not leave the cut sheet media on the Bypass Feeder for a long time as it will get
moisture. Such media will result in mis-feed or defective image.
(Keep the media in a plastic bag to block the moisture.)
Cut Sheet Guide
Feeding roller
