KIP 9900 - Manual (Page 94)

Chapter 2 Basic Operations 2-72
2. 8.14 User Mode A1 (Auto Initial Cut: Media)
Under a certain usage environment, the first print of a job sometimes would have a wrinkle or an
image void if the prints are made with a roll media left in the deck for a long period.
“Auto Initial Cut” makes an automatic initial cut in a specified amount at the leading edge before
processing a job to obtain image quality and feed balance in such conditions.
“Auto Initial Cut” can be specified which media type to be activated individually.
Setting value Plain
Bond
Tracing
Vellum
Film
0 --- --- ---
1 X --- ---
2 --- X ---
3 X X ---
4 --- --- X
5 X --- X
6 --- X X
7 X X X
2. 8.15 User Mode A2 (Auto Initial Cut: Length)
Under a certain usage environment, the first print of a job sometimes would have a wrinkle or an
image void if the prints are made with a roll media left in the deck for a long period.
“Auto Initial Cut” makes an automatic initial cut in a specified amount at the leading edge before
processing a job.
This setting can select the length to be cut of 300 / 450 / 600mm at the leading edge.
Setting value Description
600 The amount to be cut is 600mm long.
450 The amount to be cut is 450mm long.
300 The amount to be cut is 300mm long.
A shorter choice can reduce waste of media but is not enough to remove one full revolution of the
roll.
