Display
r e
t
y
u
i
o
Q0
q
w
q
Information display
The input source name, sound mode, setting values and other
information are displayed here.
w
Input signal indicators
e
MUTE indicator
This lights when the audio mute mode is selected (
).
r
Master volume indicator
t
Circle indicator
Circle indicator is displayed when the input source is “NETWORK”
or “iPod/USB” when you are playing back music.
y
Sleep timer indicator
This lights when the sleep mode is selected (
u
Tuner reception mode indicators
These light according to the reception conditions when the input
source is set to “TUNER”.
STEREO : In FM mode, this lights up when receiving stereo
broadcasts.
TUNED : Lights up when the broadcast is properly tuned in.
i
Audyssey® indicator
This indicator lights when the “MultEQ®” (
), “Dynamic
EQ” (
is set to other than “Off”.
o
Decoder indicator
These light when Dolby or DTS signals are input or when the Dolby
or DTS decoder is running.
Q0
Input mode indicators
Set the audio input modes for the different input sources
(
).
