use24 on/off: This is only valid for
SD and selects between 24bit and
20bit sound.
del off/on delay12 delay34: For
each of the embedder groups the
delay bits for ch1+2 and for ch3+4
can be inserted into the ACP. The
delay value can be positive and
negative and is put directly into the
ACP as it is written.
Note: To set both delays to 0 would
be the same as turning the delays off.
The response reflects this.
demb 0-3 - demb 0
demb 2 grp k en Audio de-embedders
one permanently assigned to each
incoming group, always enabled. No
control available.
vprc 0 lglz on |
lglz off
(y | cb | cr) <gain>
<offset> vprc 0 lglz on
vprc 0 lglz off
vprc 0 y 1.0000 0
vprc 0 cb 1.0000 0
vprc 0 cr 1.0000 0 Video processing block
Gain and offset are both signed fixed
point numbers. Gain is in 2.13-
format, while offset for Y and the
chroma channels are given in 10.2
and 9.2 respectively.
Gain range is 0
– 3.99, Gain
=0x
= 0,
Gain
=1x
= 1.0, Gain
~4x
= 3.999999
Luma Offset range is -511.75 –
511.75, Offset
=0
= 0
Chroma Offset range is -255.75 –
255.75, Offset
=0
= 0
sync 0 - sync 0 'lol' | ('lock' ('trilvl' |
'bb' | 'sdi') ) Frequency reference for video output.
Status only, no commands available.
dly 0 <frames>frms dly 0 2frms
'tgt' <frames> frms Video delay
This sets the additional video delay of
the card.
In info this block reports back the
current delay in nanoseconds. This
will vary with the incoming video
standard.
dly 1 <audio_samples>sp
s dly 1 -30sps 'tgt'
<audio_samples>
sps audio delay for deembedded audio
The audio delay is given in audio
samples. Audio delay is always given
relative to video.
dly 2 <audio_samples>sp
s dly 1 -30sps 'tgt'
<audio_samples>
sps audio delay for input AES 1
The audio delay is given in audio
samples. Audio delay is always given
relative to input AES 1.
dly 3 <audio_samples>sp
s dly 1 -30sps 'tgt'
<audio_samples>
sps audio delay for input AES 2
The audio delay is given in audio
samples. Audio delay is always given
relative to input AES 2.
dly 4 <audio_samples>sp
s dly 1 -30sps 'tgt'
<audio_samples>
sps audio delay for input AES 3
The audio delay is given in audio
samples. Audio delay is always given
relative to input AES 3.
dly 5 <audio_samples>sp
s dly 1 -30sps 'tgt'
<audio_samples>
sps audio delay for input AES 4
The audio delay is given in audio
samples. Audio delay is always given
relative to input AES 4.
dly 6 <lines>lines
<samples>sps dly 2 1lines -30sps 'phase' <lines> lines
<samples> sps Video phase
If lines != 0 the resulting phase will
