Modular 3G SD Video Rev. E

nevion.com | 10

Sync 1 and 2:

Synchronization signal 1 and 2 (in/out). Black&Burst/composite/tri-
level sync reference input with passive loop-through for vertical
interval switching.
Vertical Interval Switching Point: Manual configuration with options
fully in accordance with SMPTE RP168.

Power alarm:

Power fail alarm relay contacts. Separate contact pair for each PSU
module that is installed. Contact closes on power failure. See Chapter
2.1.1 for further description.

SW 1:

Configurations switch 1 (not in use).

SW 2:

Configurations switch 2 (not in use).
