Page 7
Modular 3G SD Video Rev. E
nevion.com | 7
Status surveillance:
On each board with LED, and via system controller.
Reclocker option:
Bypass of reclocking (from system controller).
Input Equalizer option:
Bypass of input equalization (from system controller).
Synchronization handled by
Multicon2:
Connector(s):
-
Analog Black&Burst, looped. Both PAL and NTSC
supported.
-
Tri-Level, Looped. For HD signal formats only.
-
Distribution of synchronization signals between
several routers.
BNC.
Configuration storage:
Removable compact flash card.
Other features:
-
Video switching synchronized on selectable field- and line number.
-
Monitoring output on separate channel from each module. 32x1 switch on separate
level. (Same as EDH channel).
-
SNMP agent, included with Multicon
3
.
Optional features:
Redundant control:
Redundant Matrix Control using 2x Multicon2.
2.4 Video specifications
Supported formats:
Broadcast:
-
19.4Mbps and 143Mbps
– 2.97Gbps.
-
DVB-ASI, SMPTE 259M, SMPTE 292M, SMPTE
310M and SMPTE 424M.
Electrical signal inputs, SD-SDI routers:
Standard:
SMPTE 259M.
Data rate:
19.4Mbps, 143Mbps
– 540Mbps.
Connector:
75 ohm BNC female.
Impedance:
75 ohm nominal.
Return loss:
> 15dB (5
– 540MHz).
Cable equalization:
0 to 250m, typical Belden 8281.
Electrical signal inputs, 3G/HD/SD routers:
Standard:
SMPTE 259M, SMPTE 292M and SMPTE 424M.
Data rate:
19.4Mbps, 143Mbps
– 2.97Gbps.
Connector:
75 ohm BNC female.
Impedance:
75 ohm nominal.
Return loss:
-
>15dB (5MHz
– 1.5GHz);
-
>10dB (1.5GHz
– 3GHz).
Cable equalization:
-
0 to 70m @ 3Gbps, typical Belden 1694A;
-
0 to 100m @ 1.5Gbps, typical Belden 1694A;
-
0 to 200m @ 270Mbps, typical Belden 1694A.
Electrical signal outputs, SD-SDI routers:
Connector:
75 ohm BNC female.
Impedance:
75 ohm nominal.
Return loss:
> 15dB (5
– 540MHz).
Signal level:
800mVp-p ±10%.
Signal polarity:
Non-inverting with respect to inputs.
Electrical signal outputs, 3G/HD/SD routers:
Connector:
75 ohm BNC female.
Impedance:
75 ohm nominal.
Return loss:
-
>15dB (5MHz
– 1.5GHz);
-
>10dB (1.5GHz
– 3GHz).
Signal level:
800mVp-p ±10%.
3
GYDA-VX must be applied for SNMP agent if Syscon is used; only Multicon includes SNMP agent.
