Modular 3G SD Video Rev. E

nevion.com | 15

Reset button

The reset button on the rear side is used to perform a hard reset of the card. Do not perform
a hard reset, unless the situation demands this. By performing a hard reset, the user loses
control of the router, and will not get control of the router until approximately 20 seconds after
releasing the reset button.

3.4.4 CF-card and battery

All the information regarding the router configuration, as well as information regarding control
panels that are connected to the router, is stored in the Compact Flash card on the Multicon
card.

If it is necessary to remove and/or insert a CF card, the following must be done:

1. Remove the Multicon card from its slot, according to the description earlier in this manual.

2. Slide the CF card out of its socket, and insert the new CF card into the socket.

3. Insert the Multicon card into its slot, according to the description earlier in this manual.

The battery is to ensure proper working of the on-board real time clock used by Multicon,
even when the router is powered down.

If it is necessary to remove and/or insert a battery, the following must be done:

1. Remove the Multicon card from its slot, according to the description earlier in this manual.
