22
Setting the USB input
Display: USB>***
< When set to use a High Speed mode, dedicated driver software
must be installed on the computer. Download the driver software
from our website (page 18).
NOR
Connect using USB FULL Speed mode.
The sampling frequencies that can be input are 32 kHz, 44.1 kHz,
48 kHz, 88.2 kHz and 96 kHz.
HS_1
Connect using USB HIGH Speed mode.
The sampling frequencies that can be input are 32 kHz, 44.1 kHz,
48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz and 192 kHz.
HS_2
Connect using USB HIGH Speed asynchronous mode.
The sampling frequencies that can be input are 32 kHz, 44.1 kHz,
48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz and 192 kHz.
In asynchronous mode, the clock signal of this unit is used for
playback of the audio data transmitted from the computer.
< If skipping noise occurs during playback when set to HS_2, set
the unit to HS_1 instead.
Setting the analog output
Display: A_OUT>****
RCA
Output the analog audio signals through the RCA jacks.
XLR2
Output the analog audio signals through the XLR connectors with
pin 2 HOT.
XLR3
Output the analog audio signals through the XLR connectors with
pin 3 HOT.
OFF
Disable analog outputs and turn the D/A converter OFF.
Setting the XLR output gain
Display: XLR>****
< This setting only appears when the analog output is set to XLR2 or
XLR3.
< If the sound is distorted when set to “+6dB”, change the setting to
“0dB”.
< Depending on the connected amplifier, the “+6dB” setting might
result in the same volume as the RCA jack output instead of the
“0dB” setting.
+6dB
Set the XLR output level to double the RCA output level (+6dB).
0dB
Set the XLR output level to the same level as the RCA output level
(0dB).
Setting the digital output
Display: D_OUT>***
< During SACD playback, this is automatically set to OFF.
OFF
Turns the digital output OFF
CD
Sends the CD sound to the digital outputs.
THRU
During CD playback, the digital audio signal from the CD is output.
When using external input mode, the digital sound signal from
the selected source is output. When USB is selected, the signal is
output after being converted from USB audio transmission format
to S/PDIF format.
Setting Items (2)
