GigaStudio 4 Reference Manual 41
Source Keys
The upper keyboard in the channel properties window represents the channel’s Source Keys. These incoming
MIDI note values are constant, regardless of its Destination note. Example: When you change the Source Key’s
Destination note from C2 to C3, an incoming C2 Note-On message will trigger the sample that is mapped to
C3 on that channel.
Destination Keys
The lower keyboard in the channel properties window displays the channel’s Destination Keys, which
represent the note values that are passed on to the sampler in place of the incoming Source Keys original note
value.
Channel Properties Tools
Remap/Play
The Remap/Play button (default) allows auditioning and remapping samples by dragging them from the
Source Key window into the Destination Key window. To select multiple Source keys, ctrl-click or shift-click
them.
