Figure 15: MAINTAIN TEMP Key
The Display now reads as shown below with the flashing cursor ❚ representing the
active data entry field:
PROGRAM CIRCUIT = 7❚
MAINTAIN TEMPERATURE
MAINT= 49
◦
C
Figure 16: Programming Maintain Temperature
Pressing the green UP or DOWN Arrow programming keys followed by the green
ENTER key allows the selection of the heat tracing circuit to program.
29
PN 50316_0514
