Thermon TraceNet TCM 18 User Manual
Page 35
Advertising
Figure 19: The ENTER Key
The DISPLAY screen now appears as shown in Figure 20.
PROGRAM CIRCUIT = 7❚
MAINTAIN TEMPERATURE
MAINT= 52
◦
C
Figure 20: Selecting a New Circuit Number
At this point, pressing the green UP or DOWN arrow key will select the next heat
tracing circuit to program. Alternatively, press the green PROG key to exit and re-
turn to SCAN MODE. However, if for some reason this is not done, the screen will
automatically return to SCAN mode operation after a short pause.
31
PN 50316_0514
