Specifications – Thermon TraceNet TCM 18 User Manual
Page 7
2
Specifications
The general TraceNet TC Series panel specifications are as given below.
Interior panel operating ambient range
-40
◦
F to 140
◦
F (-40
◦
C to 60
◦
C)
Exterior panel operating ambient range
-40
◦
F to 131
◦
F (-40
◦
C to 55
◦
C)
Ambient storage range
-40
◦
F to 158
◦
F (-40
◦
C to 70
◦
C)
Relative humidity range
0 to 90% Non Condensing
Nominal instrument control voltage
100 to 240 Vac, 50/60 Hz
Temperature sensor types
100 Ohm 3 Wire Platinum RTD
Control temperature range
-200
◦
F to 1112
◦
F (-129
◦
C to 600
◦
C)
Maximum power consumption of TCM18 mod-
ule
70 Watts
Current ratings in hazardous (classified) locations based on TraceNet TC Series
panels for up to 72 circuits are as follows
1
:
Maximum Panel Exterior
Ambient (
◦
C)
For: 1 - 36 Circuits
For: 37 - 72 Circuits
Maximum Allowable Average Amps per Relay
(Calculated for each side of enclosure)
2
40
22.2
18.0
45
21.0
16.8
50
19.7
15.6
55
18.3
14.3
3
