t: 1080psf @ 24
u: 1080psf @ 25
v: 1080psf @ 29.97
w: 1080psf @ 30
Note
:
All HD outputs are 10 bit YCbCr 4:2:2
c: 3G Level A Output
Selects the menu for 3G Level A video output format.
SUB-MENU c: 3G Level A Output
Selects a 3G Level A output format type of the selected resolutions:
a: 1080i @ 50
b: 1080i @ 59.94
c: 1080i @ 60
d: 1080p @ 23.97
e: 1080p @ 24
f: 1080p @ 25
g: 1080p @ 29.97
h: 1080p @ 30
i: 1080p @ 50
4:2:2 10b
j: 1080p @ 59.94
4:2:2 10b
k: 1080p @ 60
4:2:2 10b
l: 1080sf @ 23.97
m: 1080sf @ 24
n: 1080sf @ 25
o: 1080sf @ 29.97
p: 1080sf @ 30
1080p50, 1080p59.94, and 180p60 can only be YCbCr 4:2:2 10 bit. All other resolutions will proceed to
a sub-menu for color space and bit width selection.
d: 3G Level B Output
Selects the menu for 3G Level B video output format.
SUB-MENU d:
3G Level B Output
Selects a 3G Level B output format type of the selected resolutions:
a: 1080i @ 50
b: 1080i @ 59.94
c: 1080i @ 60
d: 1080p @ 23.97
e: 1080p @ 24
f: 1080p @ 25
g: 1080p @ 29.97
h: 1080p @ 30
i: 1080p @ 50
4:2:2 10b
j: 1080p @ 59.94
4:2:2 10b
k: 1080p @ 60
4:2:2 10b
l: 1080sf @ 23.97
