Strong signal open, Null – Triplett Hound 3 – PN: 3392 User Manual
Page 30
Advertising
30
STRONG
SIGNAL
OPEN
TRACER TONE
VISUAL CONT.
TALK
OFF / POLARITY
AUDIBLE CONT.
WARBLE
PULSE
CORDLESS
INTERFACE
OVERLOAD PROTECTED
UNLOCK
BATTERY TEST
AC / RING
TRIPLETT
REV NORM
NULL
Figure 7
Now, attach one of the clips and the wire attached to it to a
good earth ground. See Figure 8. The HOUND 3 should pickup
very little signal from the grounded wire. Move the HOUND
3 along the length of the wire and note how a strong signal
