Control locations, Figure 1 – Triplett Hound 3 – PN: 3392 User Manual
Page 7
Advertising
7
5: Control Locations
A
Conductive Plastic
Duckbill Tip
B
Metal Conical Tip
C
LED Headlights
D
Signal Strength Indicator
E
Power Button
F
Sensitivity Control
G
Earphone Jack
H
Battery Connector
I
Battery Strap
J
Battery
Cover
K
Battery
(not included)
L
Speaker Cover
A
B
C
D
E
F
G
H
I
J
K
L
