31
is picked up on one side of the open fault, and very little
signal is picked up on the other side of the fault.
STRONG
SIGNAL
OPEN
TRACER TONE
VISUAL CONT.
TALK
OFF / POLARITY
AUDIBLE CONT.
WARBLE
PULSE
CORDLESS
INTERFACE
OVERLOAD PROTECTED
UNLOCK
BATTERY TEST
AC / RING
TRIPLETT
REV NORM
WEAK SIGNAL
GROUND
Figure 8
For the most accurate simulation, lay out a serpentine pat-
tern on the floor similar to that in the ceiling, and locate the
open in different places, using the nulling and the grounding
