Installation Guide
Using Naked Cable
4.
Pull the network cable through the camera conduit hole.
Using Flex Conduit
Using Naked Cable
NOTE:
For camera models that support external power adaptor, audio in/out, or digital
input/output (DI/DO) functions, route the cables without connectors through the flex conduit
together with the network cable. Once cables pass through the conduit hole of the camera,
attach the bundled connectors.
NOTE:
For more information on connecting these cables, please refer to the camera model
hardware manual downloadable from the website (
www.acti.com
).
or
