Step 9: Close the Dome Cover
1.
If the dome cover has been removed, attach the dome cover to the spring wire (see
on page 31).
2.
Align the position of the dome cover shroud to the direction of the lens.
3.
Tighten the three (3) screws to attach the dome cover to the camera body.
