11
1.3.3 Display
1. Meter for displaying sound level.
2. Displayed when the key has been pressed to
indicate that you can access the subfunctions of the
keys.
3. PRIO Displayed while the priority function is ON.
4. M Displayed in the MR mode.
5. PMS Displayed in the PMS mode.
6. SKIP Displayed for memory channels which are skipped in
memory scans. Skip is user-set.
7. VFO Displayed in the VFO mode.
8. ATT Displayed when the attenuator is ON.
9. S Displayed when a frequency indivisible by the set
frequency step is entered.
10. Displayed when the bell function is ON.
11. T Displayed when the CTCSS decoder is ON.
12. Displayed when On-timer or Off-timer is ON.
13. Displayed while keys are locked.
14. BS Displayed when the battery-save function is ON.
15. Displayed when battery power is low. Promptly replace
the batteries if this icon is displayed.
16. AM Modulation mode is displayed. When the audio volume
or squelch level is being adjusted, either of them is
displayed.
17. S-meter S-meter. Depending on settings, the time or the
Channel Scope™ setting is also displayed here.
18. Dot-matrix display This is where band, channel name and frequency are
displayed in the various modes.
F
AM
1.
18.
2.3.4. 5. 6. 7. 8.
9.
10. 12.
11. 13.
14.
15.
17.
16.
