35
3.1.5 Copying data between two
receivers (CLONE)
You can copy settings stored in memory from one DJ-X2000 (master) to another
(slave). This is referred to as "cloning". Cloning requires a cable with 2.5ø stereo
plug to connect the two receivers.
1
Turn ON two DJ-X2000 units and interconnect them.
Detach the cap from the top of each unit. As illustrated below, connect the cable
between the CLN terminals.
2
Execute the cloning command.
Press the key, and then press the
key while is shown on the
display. The MENU will appear.
Point the arrow at
+CONFIG using
the dial or UP/DOWN key, and then press the
key. The CONFIG menu will appear. Point the arrow
at +CLONE , and then press the key.
The CLONE menu will appear.
Point the arrow at the desired cloning command using the
dial or
UP/DOWN key, and then press the key. This
operation is not required for the slave unit.
READ Copies the data stored in the memory from the other DJ-X2000 unit.
WRITE Copies the data stored in the memory to the other DJ-X2000 unit.
END Cancels the cloning command without copying any data.
• When READ is selected:
Displayed on the master unit Displayed on the slave unit
• When WRITE is selected:
Displayed on the master unit Displayed on the slave unit
WORK I NG
CLONE
S END I NG
CLONE DATA
WORK I NG
CLONE
R ECE I V I NG
CLONE DATA
ENT
TF
ENT
TF
HELP
SET
F
MODE
AUTO MW MIC
SCRT
PRIO
REC
CTCSS
F TUNE
A-B S
M NAME
TF
SKIP
STEP
ATT
SET
POW ER
PMS
VFO
MR M W
A B
SET
KL
3
6
9
8
0
5
2 1
4
CLR
ENT
SCN
RF C
HELP
7
MON
I
F
SRCH
LAMP
SQ
L
V
O L
D O W
N
U
P
ENT
TF
Audio plug with
2.5 mm dia. pin
WR I T E
RE AD
CLONE
+
+
