29
After finishing the setting, press the key. The display will return to the
TIMER menu. Point the arrow at END and then press the key.
(Alternatively, you may press the key, and then press the key while
is shown on the display.)
Note: • If you exit the TIMER menu by pressing the key, the setting is
canceled.
• If you set the ON timer again, the power is turned ON after the set time has
elapsed from the time when the key is pressed.
• If the battery is removed or if the hardware reset key is pressed, the setting
is canceled.
2.14 Basic modes
The DJ-X2000 has three basic modes: VFO, PMS, and MR. The current mode is
displayed along the top of the display.
• VFO mode
This mode is used to select a frequency with the dial or UP/DOWN key and then
receive signals at that frequency. The VFO mode was selected at factory.
• PMS (programmed scan-range) mode
This mode is for tuning in selected channels within a set scan range.
• MR (memory) mode
This mode is for saving often used frequencies in memory. The frequencies can
then be retrieved and tuned in.
2.14.1 VFO mode
The VFO mode has two bands: A and B.
• To enter the VFO mode
Press the key. This will engage
the VFO mode. (If the VFO mode is
already engaged, pressing the
key will switch between bands A and
B.)
To tune in frequencies or switch bands, see "2.4 Setting
frequency" on page 20 and "2.5 Switching frequency band"
on page 22.
A=B
VFO
A=B
VFO
MODE M NAME STEP
ATT
SET
PMS
VFO
MR M
W
A B
SET
3
HELP
MONI
F
SRCH
LAMP
SQL VOL
DOWN UP
HELP
SET
CLR
SKIP
HELP
SET
F
HELP
SET
N
A 1 4 5 . 3 4
b 8 .
FM
HELP
SET
