24 KARRERA — User Manual
Section 2 — User Setups and Preferences
There are four source button delegation levels with Karrera. Table 1 shows
the source to button mapping for the 1st (unshifted) and second levels for
a 35 button 3-ME system.
Table 2 shows the 3rd shifted level.
Table 3 shows the 4th shifted level.
Table 1. 3-ME Factory Configured Source to Button Mapping 1st and 2nd Levels
Panel Button
1st
(unshifted)
2nd
Buttons 1-28 Source 1 - 28 Source 29 - 56
Button 29-32 M1 A - M4 A M1 C - M4 C
Button 33,34 Shift, Shift Shift, Shift
Button 35 Delegate Delegate
Table 2. 3-ME/35 Factory Configured Source to Button Mapping 3rd Level
Panel Button (35) 3rd
Buttons 1-28 Source 57 - 84
Button 29-32 M1 B - M4 B
Button 33,34 Shift, Shift
Button 35 Delegate
Table 3. 3-ME/35 Factory Configured Source to Button Mapping 4th Level
Panel Button (35) 4th
Button 1-12 85-96
Button 13-18 IS 1 - IS 6
Button 19 eDA
Button 20 eDC
Button 21-24 Pg A - Pg - D
Button 25 Blk
Button 26 Test
Button 27,28 Bg 1,Bg 2
Button 29-32 M1 D - M4 D
Button 33,34 Shift, Shift
Button 35 Delegate
