Operating instructions | Viewfinder controls 4-5
4.2.1 Assigning functions to buttons
The camera head has three assignable buttons, two on the side panel (4) and (5), and
one on the lower front panel (19). The viewfinder has an assignable switch (22). These
buttons can be assigned the following functions:
The function and behaviour (momentary or alternating) of these buttons are set in the
INSTALL/BUTTONS menu.
Table 4-1. Button Assignments
Switch Assignment
SW1 (4) VTR Save
Switch on external signal 1
Switch on external signal 2
SW2 (5) Extended Iris
Switch on external signal 1
Switch on external signal 2
VTR Start (19) VTR Start/Stop
Switch on external signal 2
Intercom
Option (22 on VF) None
Disable camera
