37
NV9000 Web Suite
Chapter 3 provides detailed information about the DHP status portion of the NV9000 Web Suite.
Topics
Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
DHP Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Sample NV9000 Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Summary
The NV9000 Web Suite is a browser-based application that provides status for several NV9000
functions (DHP, tIelines and crosspoints) and allows users to perfom takes, breakaway, level-
mapping, locks, and protects.
Specifically applicable here are the web suite’s pages for DHP status.
Note however that the web suite does not provide any control functions for DHP.
The web suite provides a relatively simple way to view the current state of the DHP core of an
NV8500 series router. It provides data in both tabular and graphical formats.
The web suite is a browser application. Accessing the web suite depends on its location at your
facility:
• If the web suite was installed on your PC, enter “localhost” in the URL field of your browser.
• If the web suite was installed on someone else’s PC, enter the IP address of that person’s PC.
(Communicate with you system’s administrator to obtain that IP address.)
If the web suite has been set up properly, it should immediately establish communication with a
NV9000 system controller in your system. You might have to login to the web suite if you are not
already logged in. Please refer to the NV9000 Web Suite Users Guide for details.
Note:
 The web suite requires a browser that supports HTML 5, such as Firefox or Chrome.
1
The web
suite is also designed to operate well on hand-held devices such as iPads, ViewSonic tables,
Motorola Zoom tables and others. (If your browser does not support HTML 5, the web suite
will tell you.)
 At present, the web suite provides status for only one router using DHP. The NV9000 system
controller you are monitoring must have only one DHP service running.
 To use the web suite, you must have been assigned a user name and (optionally) a password.
Either you or your system’s administrator will have configured the web suite for a number of
users and for access to a specific NV9000 family system controller.
 The DHP service can communicate with only one instance of the web suite. However,
multiple users can use the same instance.
1. Internet Explorer v10 supports HTM 5.
