50
Misc. Topics
Parts
I/O Backplane Connector Modules
8500H-IP-3G-DEM-CX
Hybrid 8-input disembedder card (3Gig, HD, or SD) for use with coax con-
nectors.
8500H-IP-3G-FBR
Hybrid 8-input disembedder card (3Gig, HD, or SD) for use with SFP con-
nectors.
8500H-IP-3G-TDM-CX
Hybrid MADI input card, 8 video inputs (3Gig, HD, or SD) and 1 MADI
input, for use with coax connectors.
8500H-OP-3G-EMB-CX
Hybrid 16-output embedder card (3Gig, HD, or SD) for use with coax con-
nectors.
8500H-OP-3G-FBR Hybrid 16-output embedder card (3Gig, HD, or SD) for use with SFP con-
nectors.
8500H-OP-3G-TDM-CX Hybrid MADI card, 16 video outputs (3Gig, HD, or SD) and 2 MADI out-
puts, for use with coax connectors.
8500H-OPX-3G-EMB-CX Hybrid embedder expansion output card, 8 outputs (3Gig, HD, or SD) for
use with coax connectors.
8500H-OPX-3G-FBR Hybrid embedder expansion output card, 8 outputs (3Gig, HD, or SD) for
use with SFP connectors.
8500H-OPX-3G-TDM-CX Hybrid MADI expansion output card, 8 video outputs (3Gig, HD, or SD)
and 1 MADI output, for use with coax connectors.
Order Code Description
IO8500-3GIG-IN-COAX 8500 9IN 3GIG COAX Rear
IO8500-3GIG-IN-FIBER 8500 9IN 3GIG FIBER Rear
IO8500-3GIG-IN-SFP 8500 2IN Optical SFP Module
IO8500-3GIG-OUT-COAX 8500 18OUT 3GIG COAX Rear
IO8500-3GIG-OUT-COAX-EXP 8500 9OUT W/EXP 3GIG COAX Rear
IO8500-3GIG-OUT-FIBER 8500 18OUT 3GIG FIBER Rear
IO8500-3GIG-OUT-FIBER-EXP
8500 9OUT W/EXP FIBER Rear
IO8500-3GIG-OUT-SFP
8500 2OUT Optical SFP Module
IO8500-AES-IN-BAL
8500 9in AES BAL Rear
IO8500-AES-OUT-BAL
8500 18out AES BAL Rear
IO8500-AES-OUT-BAL-EXP
8500 9out w/EXP AES BAL rear
IO8500-IP-3G-CWDM-SFP
8500 2IN CWDM SFP
IO8500-OP-3G-CWDM-SFP-27/29
8500 2OUT 1271/1291nm, SFP
IO8500-OP-3G-CWDM-SFP-31/33
8500 2OUT 1311/1331nm,SFP
IO8500-OP-3G-CWDM-SFP-35/37
8500 2OUT 1351/1371nm, SFP
IO8500-OP-3G-CWDM-SFP-39/41 8500 2OUT 1391/1411nm, SFP
IO8500-OP-3G-CWDM-SFP-43/45 8500 2OUT 1431/1451nm, SFP
IO8500-OP-3G-CWDM-SFP-47/49 8500 2OUT 1471/1491nm, SFP
IO8500-OP-3G-CWDM-SFP-51/53 8500 2OUT 1511/1531nm, SFP
Order Code Description
