6. Tally Signalling
6 - 10 Planning and Installation - Rev. 3 / 04.2005
6.6 TALLY READY INPUT
The Tally ready function is used to generate an internal OnAir signalization without
using external tally wiring. Two cases are imaginable:
D No tally protocol is installed within the environment settings:
In this case, the TallyOverAll itself assumes PP/PGM-RED is OnAir and it gen-
erates only this default tally for its panels (TallyReady[TallyOverAll] = FALSE).
D One or more tally protocols are installed within the environment settings:
Now the Tally Ready is given individually from the MI-3040 (also for TallyOver-
All).
- If the MI-3040 is not connected, the corresponding tally is not calculated.
- If the MI-3040 is connected, the corresponding tally is calculated
according to Tally Ready input bit.
ON = Tally inputs according to input wiring,
OFF = PP/PGM-RED is assumed as OnAir
