220 Programming: Q Parameters
8.7 A
d
ditional F
unctions
Read data of the current tool, 950 1 - Tool length L
2 - Tool radius R
3 - Tool radius R2
4 - Oversize in tool length DL
5 - Oversize in tool radius DR
6 - Oversize for tool radius DR2
7 - Tool locked TL
0 = not locked, 1 = locked
8 - Number of replacement tool RT
9 - Maximum tool age TIME1
10 - Maximum tool age TIME2
11 - Current tool age CUR. TIME
12 - PLC status
13 - Maximum tooth length LCUTS
14 - Maximum plunge angle ANGLE
15 - TT: Number of teeth CUT
16 - TT: Wear tolerance in length LTOL
17 - TT: Wear tolerance in radius RTOL
18 - TT: Direction of rotation DIRECT
0 = positive, –1 = negative
19 - TT: Offset in plane R-OFFS
20 - TT: Offset in length L-OFFS
21 - TT: Break tolerance for length LBREAK
22 - TT: Break tolerance in radius RBREAK
23 - PLC value
24 - Tool type TYPE
0 = milling cutter, 21 = touch probe
27 - Corresponding row in the touch-probe table
32 - Point angle
34 - Lift off
Group name, ID number Number Index Meaning
