HEIDENHAIN TNC 320 407
16.2 Pin La
y
outs and Connecting Cables f
o
r the D
a
ta Int
e
rf
aces
Non-HEIDENHAIN devices
The connector pin layout of a non-HEIDENHAIN device may differ
considerably from that of a HEIDENHAIN device.
It depends on the unit and the type of data transfer. The table below
shows the connector pin layout on the adapter block.
Ethernet interface RJ45 socket
Maximum cable length:
„ Unshielded: 100 m
„ Shielded: 400 m
Adapter block 363 987-02 Connecting cable 366 964-xx
Female Male Female Color Female
1 1 1 Red 1
2 2 2 Yellow 3
3 3 3 White 2
4 4 4 Brown 6
5 5 5 Black 5
6 6 6 Violet 4
7 7 7 Gray 8
8 8 8 White/Green 7
9 9 9 Green 9
Hsg. Hsg. Hsg. External
shield Hsg.
Pin Signal Description
1 TX+ Transmit Data
2 TX– Transmit Data
3 REC+ Receive Data
4 Vacant
5 Vacant
6 REC– Receive Data
7 Vacant
8 Vacant
