358 8 Programming: Cycles
8.5 Cy
cles f
o
r Dr
illing, T
a
pping and Thr
ead Milling
8.5 Cycles for Drilling, Tapping and
Thread Milling
Overview
The TNC offers 16 cycles for all types of drilling operations:
Cycle Soft key Page
240 CENTERING
With automatic pre-positioning,
2nd set-up clearance, optional entry of
the centering diameter or centering
depth Page 360
200 DRILLING
With automatic pre-positioning,
2nd set-up clearance Page 362
201 REAMING
With automatic pre-positioning,
2nd set-up clearance Page 364
202 BORING
With automatic pre-positioning,
2nd set-up clearance Page 366
203 UNIVERSAL DRILLING
With automatic pre-positioning,
2nd set-up clearance, chip breaking, and
decrementing Page 368
204 BACK BORING
With automatic pre-positioning,
2nd set-up clearance Page 370
205 UNIVERSAL PECKING
With automatic pre-positioning,
2nd set-up clearance, chip breaking, and
advanced stop distance Page 373
208 BORE MILLING
With automatic pre-positioning,
2nd set-up clearance Page 376
206 TAPPING NEW
With a floating tap holder, with automatic
pre-positioning, 2nd set-up clearance Page 378
207 RIGID TAPPING NEW
Without a floating tap holder, with
automatic pre-positioning, 2nd set-up
clearance Page 380
