HEIDENHAIN iTNC 530 541
9.1 Ov
erview of Special F
unctions
Functions for contour and point machining
menu
 Select the menu for functions for contour and point
machining.
Menu for defining various plain-language
functions
 Select the menu for defining various plain-language
functions
Function Soft key Description
Assign contour description Page 487
Define a simple contour formula Page 497
Select a contour definition Page 486
Define a complex contour
formula Page 488
Define regular machining pattern Page 346
Select the point file with
machining positions Page 355
Function Soft key Description
Define positioning behavior of
rotary axes Page 566
Define file functions Page 575
Define coordinate
transformations Page 576
Define string functions Page 636
