HEIDENHAIN iTNC 530 565
9.3 Inclined-T
ool Mac
h
ining in the Tilt
ed Plane
Inclined-tool machining via normal vectors
 Retract the tool
 Activate M128
 Define any PLANE function; consider the positioning behavior
 Execute program with LN block in which the tool direction is defined
by a vector
Example NC blocks:
Only one directional vector can be defined in an LN block.
This vector defines the incline angle (normal vector NX, NY,
NZ,
or tool direction vector TX, TY, TZ).
...
12 L Z+50 R0 FMAX M128 Position at clearance height, activate M128
13 PLANE SPATIAL SPA+0 SPB+45 SPC+0 MOVE SETUP50 F1000 Define and activate the PLANE function
14 LN X+31.737 Y+21.954 Z+33.165
NX+0.3 NY+0 NZ+0.9539 F1000 M3
Set the incline angle with the normal vector
... Define machining in the tilted working plane
