8.5 Cy
cles f
o
r Dr
illing, T
a
pping and Thr
ead Milling
209 TAPPING W/ CHIP BREAKING
Without a floating tap holder, with
automatic pre-positioning, 2nd set-up
clearance, chip breaking Page 382
262 THREAD MILLING
Cycle for milling a thread in pre-drilled
material Page 387
263 THREAD MILLING/CNTSNKG
Cycle for milling a thread in pre-drilled
material and machining a countersunk
chamfer Page 389
264 THREAD DRILLING/MILLING
Cycle for drilling into the solid material
with subsequent milling of the thread
with a tool Page 393
265 HEL.THREAD DRILLING/MILLING
Cycle for milling the thread into the solid
material Page 397
267 OUTSIDE THREAD MLLNG
Cycle for milling an external thread and
machining a countersunk chamfer Page 397
Cycle Soft key Page
