286 Cycles: Coordinate Transformations
1
1
.5 MIRR
OR IMA
G
E (Cy
c
le 8, DIN/ISO: G28)
Cycle parameters
U Mirrored axis?: Enter the axis to be mirrored. You
can mirror all axes except for the spindle axis—
including rotary axes—with the exception of the
spindle axis and its associated auxiliary axis. You can
enter up to three axes. Input range: Up to three NC
axes X, Y, Z, U, V, W, A, B, C
Example: NC blocks
79 CYCL DEF 8.0 MIRROR IMAGE
80 CYCL DEF 8.1 X Y U
