332 Touch Probe Cycles: Automatic Measurement of Workpiece Misalignment
14.1 F
undamentals
14.1 Fundamentals
Overview
The TNC provides five cycles that enable you to measure and
compensate workpiece misalignment. In addition, you can reset a
basic rotation with Cycle 404:
Cycle Soft key Page
400 BASIC ROTATION Automatic
measurement using two points.
Compensation via basic rotation. Page 334
401 ROT OF 2 HOLES Automatic
measurement using two holes.
Compensation via basic rotation. Page 337
402 ROT OF 2 STUDS Automatic
measurement using two studs.
Compensation via basic rotation. Page 340
403 ROT IN ROTARY AXIS Automatic
measurement using two points.
Compensation by turning the table. Page 343
405 ROT IN C AXIS Automatic
alignment of an angular offset between
a hole center and the positive Y axis.
Compensation via table rotation. Page 348
404 SET BASIC ROTATION Setting any
basic rotation. Page 347
