HEIDENHAIN iTNC 530 479
1
8
.4 MEA
S
URE KINEMA
TICS (Cy
c
le
451, DIN/ISO: G451; Option)
4 The TNC automatically measures all three axes successively in the
resolution you defined.
5 The TNC saves the measured values in the following Q
parameters:
Parameter number Meaning
Q141 Standard deviation measured in the A axis
(–1 if axis was not measured)
Q142 Standard deviation measured in the B axis
(–1 if axis was not measured)
Q143 Standard deviation measured in the C axis
(–1 if axis was not measured)
Q144 Optimized standard deviation in the A axis
(–1 if axis was not optimized)
Q145 Optimized standard deviation in the B axis
(–1 if axis was not optimized)
Q146 Optimized standard deviation in the C axis
(–1 if axis was not optimized)
Q147 Offset error in X direction, for manual
transfer to the corresponding machine
parameter
Q148 Offset error in Y direction, for manual
transfer to the corresponding machine
parameter
Q149 Offset error in Z direction, for manual
transfer to the corresponding machine
parameter
