Tables of Cycles
21.1 Overview
21
596
TNC 640 | User's Manual Cycle Programming | 3/2014
21.1 Overview
Fixed cycles
Cycle
number Cycle designation DEF
active CALL
active Page
7 Datum shift
■
259
8 Mirror image
■
266
9 Dwell time
■
283
10 Rotation
■
268
11 Scaling factor
■
270
12 Program call
■
284
13 Spindle orientation
■
286
14 Contour definition
■
180
19 Tilting the working plane
■
273
20 Contour data SL II
■
185
21 Pilot drilling SL II
■
187
22 Rough out SL II
■
189
23 Floor finishing SL II
■
192
24 Side finishing SL II
■
193
25 Contour train
■
195
26 Axis-specific scaling
■
271
27 Cylinder surface
■
209
28 Cylindrical surface slot
■
212
29 Cylinder surface ridge
■
215
32 Tolerance
■
287
200 Drilling
■
75
201 Reaming
■
77
202 Boring
■
79
203 Universal drilling
■
82
204 Back boring
■
85
205 Universal pecking
■
88
206 Tapping with a floating tap holder, new
■
103
207 Rigid tapping, new
■
106
208 Bore milling
■
92
209 Tapping with chip breaking
■
109
220 Polar pattern
■
169
221 Cartesian pattern
■
172
225 Engraving
■
290
230 Multipass milling
■
237
231 Ruled surface
■
239
