HEIDENHAIN TNC 640 (34059x-04) Cycle programming - Manual (Page 599)

Overview 21.1
21
TNC 640 | User's Manual Cycle Programming | 3/2014
599
Touch probe cycles
Cycle
number Cycle designation DEF
active CALL
active Page
0 Reference plane
■
496
1 Polar datum
■
497
3 Measuring
■
533
4 Measuring in 3-D
■
535
30 Calibrate the TT
■
586
31 Measure/Inspect the tool length
■
588
32 Measure/inspect the tool radius
■
590
33 Measure/Inspect the tool length and the tool radius
■
592
400 Basic rotation using two points
■
416
401 Basic rotation over two holes
■
419
402 Basic rotation over two studs
■
422
403 Compensate misalignment with rotary axis
■
425
404 Set basic rotation
■
428
405 Compensate misalignment with the C axis
■
429
408 Reference point at slot center (FCL 3 function)
■
440
409 Reference point at ridge center (FCL 3 function)
■
444
410 Datum from inside of rectangle
■
447
411 Datum from outside of rectangle
■
451
412 Datum from inside of circle (hole)
■
454
413 Datum from outside of circle (stud)
■
459
414 Datum from outside of corner
■
463
415 Datum from inside of corner
■
468
416 Datum from circle center
■
472
417 Datum in touch probe axis
■
476
418 Datum at center between four holes
■
478
419 Datum in any one axis
■
482
420 Workpiece—measure angle
■
498
421 Workpiece—measure hole (center and diameter of hole)
■
501
422 Workpiece—measure circle from outside (diameter of circular stud)
■
504
423 Workpiece—measure rectangle from inside
■
507
424 Workpiece—measure rectangle from outside
■
510
425 Workpiece—measure inside width (slot)
■
513
426 Workpiece—measure outside width (ridge)
■
516
427 Workpiece—measure in any selectable axis
■
519
430 Workpiece—measure bolt hole circle
■
522
431 Workpiece—measure plane
■
522
