Fundamentals

TNC model, software and features

6

TNC 640 | User's Manual Cycle Programming | 3/2014

Software option 2

(option number 09)

■

Motion control with minimum jerk

■

3-D tool compensation through surface normal vectors

■

Using the electronic handwheel to change the angle of the swivel head
during program run without affecting the position of the tool point.
(TCPM =

T

ool

C

enter

P

oint

M

anagement)

3-D machining

■

Keeping the tool normal to the contour

■

Tool radius compensation perpendicular to traversing and tool direction

Interpolation

■

Linear in 5 axes (subject to export permit)

HEIDENHAIN DNC

(option number 18)

■

Communication with external PC applications over COM component

Display step

(option number 23)

■

Linear axes down to 0.01 µm

Input resolution and display
step

■

Rotary axes to 0.00001°

Dynamic Collision Monitoring (DCM) software option

(option number 40)

■

The machine manufacturer defines objects to be monitored

■

Three warning levels in manual operation

■

Program interrupt during automatic operation

Collision monitoring in all
machine operating modes

■

Includes monitoring of 5-axis movements
