Epson WorkForce DS-860 - Manual (Page 68)

Image data 16 bits per pixel per color internal
1 bit, 8 bits per pixel per color external
Interface One Hi-speed USB port
Light source RGB LED
Mechanical
Dimensions Width: 300.0 mm (11.8 inches)
Depth: 166.0 mm (6.5 inches)
Height: 158.0 mm (6.2 inches)
* Not including input tray
Weight Approx. 4.0 kg (8.8 lb)
Electrical
Product
Rated input current 2.00 A
Rated input voltage DC 24 V
Rated input frequency 50 to 60 Hz
Power consumption Approx. 42.0 W Operating
Approx. 8.0 W Ready Mode
Approx. 1.6 W Sleep Mode
Approx. 0.4 W Power off
Note:
Power consumption varies depending on operating conditions and whether an option is installed.
AC Adapter
AC adapter model A421H
Rated input voltage AC 100 to 240 V
Rated input current AC 1.20 A
Rated input frequency 50 to 60 Hz
Rated output voltage DC 24 V
Rated output current 2.00 A
DS-860 User’s Guide
Technical Specifications
68
