Canon PIXMA E474 - Manual (Page 117)

*1 USB connection to PC
*2 The wait time for standby cannot be changed.
External dimensions Approx. 16.8 (W) x 12.1 (D) x 5.8 (H) inches
Approx. 426 (W) x 306 (D) x 145 (H) mm
* With the Paper Support and Paper Output Tray retracted.
Weight Approx. 7.6 lb (Approx. 3.5 kg)
* With the FINE Cartridges installed.
Canon FINE Cartridge Total 1280 nozzles (BK 320 nozzles, C/M/Y each 320 nozzles)
Copy Specifications
Multiple copy max. 21 pages
Scan Specifications
Scanner driver Windows: TWAIN 1.9 Specification, WIA
Mac OS: ICA
Maximum scanning size A4/Letter, 8.5" x 11.7"/216 x 297 mm
Scanning resolution Optical resolution (horizontal x vertical) max: 600 x 1200 dpi *1
Interpolated resolution max: 19200 x 19200 dpi *2
*1 Optical Resolution represents the maximum sampling rate based on ISO
14473.
*2 Increasing the scanning resolution will limit the maximum possible scanning
area.
Gradation (Input / Output) Gray: 16 bit/8 bit
Color: 48 bit/24 bit (RGB each 16 bit/8 bit)
Network Specifications
Communication protocol TCP/IP
Wireless LAN Supported Standards: IEEE802.11n / IEEE802.11g / IEEE802.11b
Frequency bandwidth: 2.4 GHz
Channel: 1-11 or 1-13
* Frequency bandwidth and available channels differ depending on country or
region.
Communication distance: Indoors 164 feet/50 m
* Effective range varies depending on the installation environment and location.
Security:
WEP (64/128 bits)
117
