Loading Originals on the Platen Glass
1. Load an original on the platen glass.
1. Open the document cover.
Important
• Do not place any object on the document cover. It will fall into the rear tray when the document cover
is opened and cause the printer to malfunction.
2. Load the original WITH THE SIDE TO SCAN FACING DOWN on the platen glass.
Align the corner of the original with the alignment mark .
Important
• Be sure to observe the following when loading the original on the platen glass.
• Do not place any objects weighing 4.4 lb (2.0 kg) or more on the platen glass.
• Do not put any pressure of 4.4 lb (2.0 kg) or more on the platen glass, such as pressing down
the original.
Failure to observe the above may cause the scanner to malfunction or the platen glass to break.
• The printer cannot scan the striped area (A) (0.04 inch (1 mm) from the edges of the platen glass).
