Operation Panel

* All lamps on the operation panel are shown lit in the figure below for explanatory purposes.

(1) ON button

Turns the power on or off. Before turning on the power, make sure that the document cover is closed.

(2) ON lamp

Lights after flashing when the power is turned on.

Note

• You can check the status of the printer by the ON and Alarm lamps.

ON lamp is off: The power is off.
ON lamp lights: The printer is ready to print.
ON lamp flashes: The printer is getting ready to print, or printing is in progress.
Alarm lamp flashes: An error has occurred and the printer is not ready to print.
ON lamp flashes and Alarm lamp flashes alternately: An error that requires contacting the service

center may have occurred.

An Error Occurs

(3) Wi-Fi button

Hold down to automatically set up the wireless connection. You can also press this button to switch the
wireless connection method.

(4) Wi-Fi lamp

Lights or flashes to indicate the wireless LAN status.

Lights:

Wireless LAN is enabled. Also lights when the printer is connected to the wireless router.

81
