Specifications, Definitions – Rosen Aviation 0602 Series : Dual Blu-ray Player User Manual
Page 39
Rosen Aviation
Dual Blu-ray DVD Player
Document Number: 104185
Revision: D
Date: 05/28/15
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 39 of 41
9.3. Specifications
The specifications in the following tables apply to each drive for both models of Dual Blu-ray
players.
Table 10 Model 0602-200 (no media share) specifications
Nominal Voltage/Current Draw
28VDC/0.8A
Inrush Current
44A
Op Voltage Range
18-32VDC
Maximum Current Draw
1.28A
Power Consumption
23W
Weight
5.12 lbs [1.42 kgs.] ± 5%
Operating Temperature
0ºC
– 45ºC
Table 11 Model 0602-205 and 0602-201 (with media share) specifications
Nominal Voltage/Current Draw
28VDC/0.9 A
Inrush Current
44A
Op Voltage Range
18-32VDC
Maximum Current Draw
1.36A
Power Consumption
25W
Weight
5.45 lbs [2.47 kgs.] ± 5%
Operating Temperature
0ºC
– 45ºC
10. DEFINITIONS
3G HD-SDI High-definition SDI with 3 gigabit/s data rate transfer
CFR Code of Federal Regulations
CVBS Composite Video Baseband Signal
DC Direct Current
DNS Domain Name System
DTS-MA Digital Theater System High Definition Master Audio
DVI Digital Visual Interface
HD High Definition
HDCP High-Bandwidth Digital Content Protection
HDMI High Definition Multimedia Interface
HD-SDI High Definition Serial Digital Interface
IP Internet Protocol
