6-5
Status Menu
If the entire name shown as the Job Name will not fit on one line,
pressing [Detail] ([Right Select]) changes to a 3-line name
display.
USB Keyboard
When a USB keyboard is attached, it is possible to check whether the USB keyboard can be used.
1
In the Status menu, press or to select USB Keyboard.
2
Press [OK]. If the USB keyboard is available for use, Available is
displayed.
Wireless Network
When the optional wireless network interface kit is installed, it is possible to check the status of the wireless network.
1
In the Status menu, press or to select Wireless network.
2
Press [OK]. The status of the wireless network is displayed.
3
Press or . The NetwkName(SSID) is displayed.
If the entire name shown as the NetwkName(SSID)will not fit on one
line, pressing [Detail] ([Right Select]) changes to a 3-line name
display.
Detail:
O
b
ABCDEFGHIJKLMNOPQRSTU
VWXYZabcdefghijklmnop
qrstuvwxyz1234567890
USB Keyboard: b
Available
Note Wireless Network is only displayed when the optional wireless network interface kit is installed.
Wireless network: P
b
Status:
1/2
Connection
Wireless network: P
b
NetwkName(SSID):
2/2
ABCDEFGHIJKLMNOPQRSTN
[ Detail ]
Detail:
O
b
ABCDEFGHIJKLMNOPQRSTU
VWXYZabcdefghijklmnop
qrstuvwxyz1234567890
