POE-161S:
Interface
2-Port RJ-45 interfaces
1-Port PoE Power+ Data input
1-Port Data output
1 DC out plug connector
PoE
Complies with IEEE 802.3at Power over Ethernet pre-stan-
dard, PD
Splits the 56V DC power over RJ-45 Ethernet cable into DC
5V/12V output
Up to 1 non-IEEE 802.3at devices powered
Auto-detect of PoE IEEE 802.3at equipment, protect devices
from being damaged by incorrect installation
Adjustable two different output voltage options (5V/4.5A,
12V/2A) to fit various devices
Distance up to 100 meters
IEEE 802.3af Injector devices compatible
Hardware
Plastic case
5V /12V DIP switch
LED indicators power input indication
Standard Compliance
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3ab 1000Base-T
IEEE 802.3at Power over Ethernet pre-standard
FCC Part 15 Class A, CE
