9.ET-508 Technical Specifications
Models: ET-508:Hdx/Fdx
TP-Fiber
Converter
Standards: IEEE802.3
10Base-T/10Base-FL
TP Port:
RJ-45 jack with a slide switch for "DTE" or "MPR" selection
Fiber Port:
ST connector
TP Cable:
UTP Cable: Cat. 3 or 5 cable, up to 100m
Fiber Cable:
50/125, 62.5/125, or 100/140 m multi-mode, up to 2000m
Data Transfer Rate:
10Mbps/20Mbps Auto-Negotiation via TP port
LED Indicators:
Power, FL Link/Act, TP Link/Act
Power Requirement: 1A@+5VDC
Ambient Temperature: 0 to 50 C
Humidity:
5% to 90%
Dimensions :
26.2(H) 70.3(W) 90(D) mm
Note:
Connecting to Router, Bridge, or Switch, Hub, please refer to the device's
Technical Manual.
10.DC Power Jack and AC-DC Power Adapter
The DC jack's central post is 2.5mm wide, it conforms to the DC receptacle
(2.5mm) on the 10/19-inch Converter Rack slot.
Keep the AC-DC adapter as spare parts when Media
converter is installed in a Media Converter Rack.
AC-DC power adapter
AC Input 100~240VAC 50/60Hz
DC Output:1A@+5VDC
Part No:2010-000009-001
