EN
11
Synchronizing the power supply with
external devices (trigger function)
The power supply of this unit can be synchronized with a connected
preamp or other device that supports trigger functions.
Use commercially-available mono mini plug cables for connections.
ATTENTION
To use the trigger function, set this unit’s STANDBY/ON switch to
ON.
12V TRIGGER connectors
IN
Connect this to the trigger output connector of a preamp or other
device.
This will make the power operation of that preamp or other device
control this unit, putting it in standby and turning it on.
THRU (through output)
Signals input through the IN connector are output unchanged.
By connecting this to a device that supports trigger input (e.g. a
power amplifier or subwoofer), its power supply can also be syn-
chronized with the device connected to this unit’s IN connector.
When in BI-AMP mode, connect the THRU
and IN connectors as shown in the illustration.
Device that supports
trigger output
(preamp, etc.)
12V TRIGGER OUT
Mono mini plug cable
M
ono mini plug c
able
