CLA MixHub / User Guide
17
Controls
Processing Modules
Processing module controls are the same in the Channel and Bucket Views. However, certain switches and displays
differ in appearance between the two. In the Channel View, the Input, Dynamics, and EQ modes, parameter values
are shown on the controls. In the Bucket View, parameter values are not shown.
Top Section (Common to Input, EQ, and Dynamics Modules)
There are six controls at the top of each Track strip in the Input, EQ, and Dynamics modules.
Module On/Off turns off the module and removes it from the DSP. Audio continues to pass to the next module when
processing is turned off.
Track Name is copied from the DAW track assigned to this bucket.
Module Type display—In the Buckets mode, all tracks display the same processing module type.
Open Expanded View.
Clip light LED turns red when the module input is 4 dB or less from clipping internally.
Stereo Mode selector sets the format of audio in the module (L/R stereo, DUO—split for dynamics processing, M/S)
Mono Module Stereo Module
