DJI O3 Air Unit User Manual
Menu
Status
Album
Transmission
Setting
More
Switch
1
2
3
4
5
Image transmission signal weak
DJI O3 Air Unit
1. Status
Displays the information of prompts or alerts.
Use the switch function to change the aircraft used (only available on DJI Goggles 2).
2. Album
Manage or view the photos or videos stored on the microSD card.
3. Transmission
The transmission menu includes the following settings:
Enable or disable the broadcast mode. When the broadcast mode is enabled, other devices can
find the goggles and enter the channel to see the camera view.
Set the focus mode to on, off, or auto.
Set the channel mode to auto or manual. In manual mode, users can select a channel manually
from 10 MHz, 20 MHz, and 40 MHz bandwidth.
If any nearby video transmission device turns on the broadcast mode, the device can be found in
the audience mode. The user can select a device to see the camera view of that device.
4. Settings
Control (only available for DJI remote controller): Set the stick mode and calibrate the remote
controller.
Camera: Set shooting related functions and parameters, or format the microSD card.
Note that the data cannot be recovered after formatting. Operate with caution.
Display: Adjust screen brightness and zoom.
About: View device information, such as the serial number and the firmware of the goggles and
linked air unit. Set the system language. Reset the goggles and the linked air unit to the default
settings.
5. More (only available on DJI Goggles 2)
The screen casting function enables you to cast the video playing on the mobile device to the
goggles screen (the video player must support the screen casting function).
