Channels Info
Supports auto mode and manual mode
Manual mode:
40 MHz: 1 channel: 5794.5 MHz
20 MHz: 3 channels:
Channel 1: 5768.5 MHz
Channel 2: 5804.5 MHz
Channel 3: 5839.5 MHz
10 MHz: 3 channels
Channel 1: 5768.5 MHz
Channel 2: 5804.5 MHz
Channel 3: 5839.5 MHz
Operating Temperature
-10° to 40° C (14° to 104°F)
Power Input
7.4 V–26.4 V
Weight
Air unit (camera module included and Dual-Band Dual-Polarized
Antenna excluded): Approx. 36.4 g
Dual-Band Dual-Polarized Antenna: Approx. 3 g
3-in-1 cable: Approx. 1.2 g
Transmission
O3+
Operating Frequency
2.400-2.4835 GHz (Rx)
5.725-5.850 GHz (Tx/Rx)
[1]
Transmitter Power (EIRP)
FCC: <33 dBm; SRRC: <30 dBm; CE: <14 dBm
Min. Latency (end-to-end)
[2]
Used with DJI Goggles 2:
1080p/100fps: 30 ms
1080p/60fps: 40 ms
Used with DJI FPV Goggles V2:
810p/120fps: < 28 ms
810p/60fps: < 40 ms
Max. Transmission Distance
[3]
FCC: <10 km; SRRC: <6 km; CE: <2 km
Storage
Approx. 20 GB
Camera Module
Image Sensor
1/1.7” CMOS
Lens
Equivalent Focal Length: 12.7 mm
Focal Length: 2.34 mm
Aperture: f/2.8
Focus Mode: FF
Focus Range: 0.6 m to ∞
Shutter
Rolling shutter
ISO
100-6400 (Auto)
100-25600 (Manual)
